SQL Table Format

General Guidelines

This section describes the guideline for the SQL Table based integration.

SQL Table Diagram

SQL Table Description

Ultriva Integration server monitors UEK over HTTP/S or LAN and moves the data between UEK and Integration DB.

Custom Integration Modules are modules developed by customer or Ultriva to access MRP/ERP data and creates/processes event data in the Integration DB.

Integration DB runs in the Corporate LAN that stores the data from UEK and Customer MRP/ERP systems.
